Built in more than ten commonly used standards, including SAE4059E, SAE4059F, SAE4059F-CPC, NAS1638, ISO4406, GB/T14039, GJB-420A, GJB-420B, Г OCT17216-71, DL/T1096, SAE749D, JBT9737.1, QC/T29104-201, DL-T432-2018, HH005-2018, etc., can provide data results for all built-in standards in one test;

According to customer requirements, 64 channels can be customized simultaneously, and particle size can be set arbitrarily;

Equipped with a Windows operating interface, built-in database, unlimited data storage, and can be searched and queried using various methods such as testing standards, sample names, sample batch numbers, testing personnel, testing time, etc;

Multi level account permission management, allowing for separate account permissions and supporting digital signatures;

The test results can be printed using a micro or desktop printer, and can be exported in PDF, Excel, and other formats. They can be transmitted through WiFi, Bluetooth, and other methods.

Among them, the use of Windows 10 and above operating systems is also a pioneering technology both domestically and internationally, allowing precision instruments to achieve more "foolproof" operation.

Adopting high-pressure injection pump sampling method, the sampling volume can be set by oneself, the injection speed is stable, and the sampling accuracy is high;

Built in pressure sensor, which can directly set the pressure value and automatically determine the pressure inside the cabin to ensure safety;

The host is equipped with an air purification system (including a micro mist separator, oil mist separator, and moisture filter) to ensure that testing is not contaminated; Higher integration, minimizing instrument weight and reducing the burden on external air pumps;

The net weight of the instrument is 25KG, and the net weight of the air pump is 6KG, making the overall quality lighter;

Optional viscosity, dielectric constant, moisture, and temperature sensor modules are available, with one precision and multiple capabilities to achieve multi parameter testing.

To ensure uniform particle suspension, the Honghe desktop particle counter pressure chamber is equipped with a magnetic stirrer; If the detected liquid sample contains ferromagnetic particles, the particles will quickly settle under the magnetic field of the magnetic stirrer, thereby affecting the detection results. Therefore, if it is suspected that the detected liquid sample contains ferromagnetic particles, the magnetic stirrer should be turned off first before using a desktop particle counter for detection.

In environments with high humidity, the air filtration combination may retain some moisture, leading to the failure of the filtration combination. You can observe through the observation window on the back panel of the instrument and perform drainage operations in a timely manner (by manually unscrewing the bottom drainage port, the internal water can be drained).
